AURUM MANTO

Premium Gravel Bikes designed by Ivan Basso and Alberto Contador

UNBOUND PERFORMANCE

Simply put, it’s a MAGMA for gravel. It follows the same principles and same high-performance spirit as MAGMA, but with bigger wheels and gravel specific geometry. It takes all the riding and testing experience from Alberto and Ivan, then adds all the experience from AURUM to design and develop a top-level bicycle.

AURM MANTO - Sram RED - Zipp 303

Discover more...

GRAVEL WITHOUT CABLES:
MANTO FLOWS WITHOUT OBSTACLES

The front end of the MANTO stands out for its subtle blend of airfoil headtube and downtube profiles into the oversized fork crown. Beyond that aero-efficient shaping, the headtube also routes the brake hoses in a clean and simple way through the 1.5″ headset bearing, to expose nothing to the wind and keep everything clean and tidy. This solution is also clean and helpful when using handlebar mounted bags, so the cables don’t interfere with the straps.

GEOMETRY

Size	48	51	54	56	58
	152-163cm	161-170cm	170-177cm	175-181cm	180-188cm
A. Stack	505	525	545	567	589
B. Reach	370	376	384	392	400
C. Seat Tube Angle	74	73	73	73	73
D. Top Tube	515	536	551	565	580
E. Head Tube Angle	71.8	71.6	73	73	73
F. Fork Offset	50	50	44	44	44
G. Fork Trail	60	60	59	59	59
H. Seat Tube Length	453	480	504	526	547
I. BB Drop	74	71	71	71	71
J. Front Center	570	584	580	594	608
K. Chainstay Length	407	407	410	410	410
L. Wheelbase	965	980	979	993	1008
M. Stand Over Height	728	750	782	803	826
N. Head Tube Length	102	127	143	166	189
O. Fork Length	367	367	365	365	365

SERVICE

Visit our service page on how to take care of your bike, how we can help you and easy uncomplicated spares that can be easily ordered online.

Discover more..

WARRANTEE

We offer two years warranty on paint and ten years on frame and fork. We will only handle warranty issues of frames that have been registered online and have been serviced twice a year.

Discover more..
